Differential Pressure Gauge


Differential Pressure Gauge

MOQ : 1 Piece

Business Type Manufacturer, Exporter, Supplier, Retailer
Accuracy +/- 1% FSD
Enclosure SS 304
Sensing Element SS316 Diaphragm
Click to view more

Preferred Buyer From

Location Worldwide

Product Details

Process Connection
Threaded ¼” NPT M/F
Diaphragm Chamber
SS304
Dial Size
100mm / 150mm
Pressure Range
Vacuum -760mmhg upto 70 Kg/Sqcm
Static Pressure
Upto 100 Kg/Sqcm (upto 200 Kg/Sqcm on request)
Mounting
Direct
Entry
Back

Differential pressure gauges measure the difference between two pressures. Pressure Gauge has two different port which are connected to the system, the pressure difference of which is to be measured. On sensing the pressure difference from the systems the internal sensing element deflects, transmitting the pressure to the movement, which converts it in the rotation of a concentric pointer on a dial, similar to regular pressure gauges. Marking on the dial indicate the difference in the Pressure.

Special Features

  • Direct Reading Gauge
  • All SS304 / SS316 Conctruction
  • Static Pressure upto 100 Kg/Sqcm
  • Dry & Liquid filled Variant
  • Rugged construction
  • Manufactured as per Industrial Standards.
  • Available in various mounting arrangements.


Application
They are suitable for the monitoring of filter contamination, for level measurement in closed vessels, for overpressure measurement in clean rooms, for flow measurement of gaseous and liquid media and for the control of pumping plants.

Major Industries
Fertilizer, Petrochemicals, Pharmaceutical, Power, Cement, Sugar, Food & beverages, Pulp, Paper, Allied process industries
